MEGA PLUS 480

Optical System:

• Light source: OSRAM SIRIUS HRI@470W
• Zoom angle: 2.5-45degree

Specifications:

• Control: DMX512, master/slave, sound, auto mode
• Pan/Tilt: 540-270 degree
• Net Weight: 24.5kg
• Gross Weight: 28kg
• Dimension: 405x245x685mm
• Packing size: 540x450x650mm

     Electrical spec:

• Power connection: Power in & out

     Features:

• Colour wheel: 11 colours + 2700K+3200K+white+CMY colour mixing system
• Fixed gobo wheel: 14 fixed gobos+ open, wheel rotation & shake
• Rotation gobo: 9 rotation gobos + open, changeable, wheel rotation & shake
• Prism Wheel 1: 8 facet prism +linear 6 facet prism + cylindrical prism
• Prism Wheel 2: 8 facet prism + linear 6 facet prism + double layer prism
• Focus, Frost effect, Overheat Protection
